Key Features:
- Accepts 2, 3 or 4-wire 100 Ω Platinum RTDs
- Continuous Monitoring
- Configurable Alarms & Notifications
Suitable for:
- Clinical trials
- Appliance validation
- Critical vaccine storage alarm with audible warning
Hardware Features
- USB and Wireless connectivity
- Temperature data logger
- Email and audible alarms
- LCD display
- Battery or optional mains power supply.
- Cloud services compatibility
Application:
- Clean Rooms
- Laboratories and Hospitals
- Medical and Pharmaceutical
Specification
General
| Memory | 21,504 readings |
| Reading Rate | 1 reading every second up to 1 reading every 24 hours |
| Baud Rate | 250,000 |
| LED Indicators | Green, Blue & Red |
| Battery Life | 3 years typical at a 1 minute reading rate |
| Material | ABS plastic |
| Dimensions | 3.0 in x 3.5 in x 0.95 in (76.2 mm x 88.9 mm x 24.1 mm) – Data logger only |
| IP Rating | IP22 |
| Operating Environment | -20 °C to +60 °C (-4 °F to + 140 °F), 0 %RH to 95 %RH non-condensing |
| Required Interface Package | RFC1000 |
| Approvals | US (FCC), CA (IC), CE, South Korea (KCC), China (CMIIT), Japan (LCIE) |
Temperature
| External Temperature Sensor | 100 Ω Resistance Temperature Detector (RTD) |
| External Temperature Range | 18.5 Ω to 390.5 Ω; -200 °C to +850 °C (-328 °F to +1562 °F) (Probe Dependent) |
| External Temperature Resolution | 0.005 Ω; 0.001 °C (0.0018 °F) (Probe Dependent) |
| External Temperature Calibrated Accuracy | ±0.015 Ω; ±0.04 °C (±0.072 °F) (Probe Dependent) |
| Internal Temperature Sensor | Internal Semiconductor |
Wireless
| RF Carrier Frequency | 2.45 GHz IEEE 802.15.4 ultra-low power MadgeNET Wireless Transceiver with fully by-directional communication. |
| Output Power | +0 dBm typical |
| Receiver Sensitivity | -95 dBm typical |
| Typical outdoors Line of sight | Up to 2000 ft |
| Typical Indoors line of sight | Up to 500 ft |
